Category: Fieldbus
- Supports unicast and multicast CIP connections
- TB20 ToolBox can be used for easy access to assembly sizes and to the structure of the image table within the assemblies
- Modules can be replaced during operation (hot-plug)
- Implicit messaging (·transport class 1)
- Explicit messaging (transport class 3)
- TCP watchdog
- IP address can be set relative to a base IP address by using a DIP switch that can be covered
- Integrated two-port switch with two RJ45 connectors
- Module process data is automatically assigned to the EtherNet/IP mapping
- Integrated power supply unit for powering peripheral modules (2.5 A)
- 9 LEDs, three of them bi-color
- USB device port for online diagnostics, configuring parameters, setup, and firmware updates with “GBS20 ToolBox”
- GBS20 ToolBox simulation for setting up the I/O system without a higher-level controller in order to test the system's operation (I/O check)
